LPIC-102

www.nobleprog.com

title: LPIC-102
author: Tytus Kurek (NobleProg)

Copyright Notice

This publication is protected by copyright, and permission must be obtained from the publisher prior to any prohibited reproduction, storage in a retrieval system, or transmission in any form or by any means, electronic, mechanical, photocopying, recording, or likewise.

What does Linux mean?⌘

http://upload.wikimedia.org/wikipedia/commons/thumb/3/35/Tux.svg/512px-Tux.svg.png

LINUX = LINUs' uniX

Outline⌘

First Day:
- Session I:
  - Introduction to the course
- Session II:
  - Topic 105: Shells, Scripting and Data Management
- Session III:
  - Topic 106: User Interfaces and Desktops
- Session IV:
  - Topic 107: Administrative Tasks

Outline #2⌘

Second Day:
- Session I:
  - Topic 108: Essential System Services
- Session II:
  - Topic 109: Networking Fundamentals
- Session III:
  - Topic 110: Security
- Session IV:
  - Case Study, Certification and Surveys

First Day - Session I⌘

Introduction

http://shop.linuxnewmedia.com/media/catalog/product/cache/17/image/9df78eab33525d08d6e5fb8d27136e95/l/p/lpic1_large_6.gif

LPI certification path⌘

LPIC-101 exam⌘

Detailed Objectives: https://www.lpi.org/linux-certifications/programs/lpic-1/exam-101/
Certification Authorities:
- PearsonVUE: http://www.pearsonvue.com/
- Prometric: https://www.prometric.com/en-us/Pages/home.aspx
Exam Cost: 173$ (prizes in local currency updated on a daily basis)
Exam Duration: 90m base time + 30m additional time for piloting questions
Exam Passing Score: 500 in 200 - 800 scale
Certificate Expiration Date: 5 years
Question Type: closed
Exam Topic Weigths

Introduction to the lab⌘

Lab components:

Laptop with Windows
Virtual Machines with Linux on:
- VMs: Debian, CentOS
- Credentials:
  - admin user: root / terminal
  - non-admin user: terminal / terminal
VirtualBox:
- 64-bit version (click here to download)
- Snapshots (top right corner)
- Press right "Control" key to release

First Day - Session II⌘

Topic 105: Shells, Scripting and Data Management

http://www.thelinuxblog.com/uploads/optimizing-shell-scripts.jpg

105.1 Customize and use the shell
environment⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Environmental Variables⌘

Environmental variable - variable defining a behavior of the environment
Management tools:
- env - displays set environmental variables
- export - causes the environmental variable to be inherited by child processes
- set - sets a value of the environmental variable
- unset - unsets a value of the environmental variable
The most common environmental variables:
- HOSTNAME - system hostname
- USERNAME - username
- PATH - paths in which to search executables
- PWD - current working directory
- LANG - locale category

Bash configuration files⌘

Common bash configuration files:

Type of File	Login File Location	Non-Login File Location
Global	/etc/profile and files in /etc/profile.d directory	/etc/bashrc or /etc/bash.bashrc
User	~/.bash_login, ~/.profile or ~/.bash_profile	~/.bashrc

Additional bash configuration files and directories:
- /etc/skel - skeleton directory for new user accounts
- ~/.bash_logout - user logout script
- ~/.inputrc - keyboard shortcuts configuration

Other bash customization tools⌘

Aliases:
- defined by an alias built-in:

alias [alias]="[command]"

Functions:
- defined by a function keyword

function [name] {
    ...
}

Lists:

list=(item1 item2)
list[2]=item3
echo ${list[0]} ${list[1]} ${list[2]}

Lab Exercise 105.1

105.2 Customize or write simple scripts⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Bash scripting foudations⌘

Execution permissions
#! (shebang) - defines a path to the interpreter
The most common Linux interpreters:
- /bin/bash (Bourne Again SHell)
- /bin/sh - standard shell
- /bin/tcsh (The C Shell)
- /usr/bin/expect
- /usr/bin/perl
- /usr/bin/python

IO Operations⌘

Input operation:

read [variable]

Output operation:

echo [output]

Reading from file:

cat [file]

Writing to file:

[command] > [file]

Conditional expressions⌘

test:

test [expression] && [true command] || [false command]

if:

if [ [expression] ]
then
    [true command]
else
    [false command]
fi

case:

case [word] in
    [pattern 1]) [command 1] ;;
    [pattern 2]) [command 2] ;;
    ...
    *)           [command n] ;;
esac

Loops⌘

for:

for [variable] in [list]
do
    [command]
done

seq:

seq [start] [stop]

while:

while [ [condition] ]
do
    [command]
done

Lab Exercise 105.2

105.3 SQL data management⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

SQL and RDBMS⌘

RDBMS (Relational DataBase Management system):
- database management system that is based on relational model
- the most popular Linux open-source RDBMS:
  - MySQL - http://www.mysql.com/
  - PostgreSQL - http://www.postgresql.org/
  - SQLite - http://www.sqlite.org/
SQL (Sequential Query Language):
- programming language designed for managing data held in a RDBMS
- SQL is an interpreted language
- de facto standard for managing structured data

Basic SQL commands⌘

SELECT - retrieves data from one or more tables
FROM - specifies the table(s) from which data is to be retrieved
WHERE - includes a comparison predicate, which restricts the rows returned by the query
GROUP BY - used to project rows having common values into a smaller set of rows
ORDER BY - identifies which columns are used to sort the resulting data
JOIN - used to join query results from two tables into one table
INSERT - adds data to a table in a form of row
INTO - specifies the table into which data is to be insterted
VALUES - specifies the data to be insterted
UPDATE - modifies a set of existing table rows
SET - specifies the data to be modified
DELETE - removes existing rows from a table
Lab Exercise 105.3

First Day - Session III⌘

Topic 106: User Interfaces and Desktops

http://www.blogporta80.com.br/conteudo/2011/09/07/gnome_kde_xfce.png

106.1 Install and configure X11⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

What is X11?⌘

X11 - The X Window System - http://www.x.org/wiki/
Windowing system for bitmap displays
The most common GUI for UNIX-like operating systems
Responsibilities:
- interacting with mouse and keyboard as an input device
- interacting with displays as an output device
- X11 does not mandate user interface!
Principles of operations:
- client / server architecture
- network awareness
- x window manager
List of supported video cards: http://www.x.org/wiki/Projects/Drivers/

History of X11⌘

1973 - first bitmap diplay system by Xeros (Alto)
1983 - initial idea of the X Window System
1985 - first release of the UWM (Ultrix Window Manager)
1987 - first release of the X11 system
1988 - first release of the XDM (X Display Manager)
1991 - fork between the MIT X Consortium and the XFree86 Project, Inc.
1993 - the MIT X Consortium transitions into the X Consortium, Inc.
1997 - the X Consortium, Inc. transitions into The Open Group

History of X11 #2⌘

1998 - first release of the KDE (K Desktop Environment) desktop
1999 - first release of the Gnome desktop
2004 - establishment of the X.Org Foundation
2004 - fork between the X.Org Foundation and the XFree86 Project, Inc.
2008 - last release of the XFree86 server
2009 - last commit into the XFree86 project
2014 - latest release of the X.Org Server

Desktops⌘

X Window Manager + Additional Software = Desktop
The most popular Linux desktops:
- GNOME - http://www.gnome.org/
- KDE - http://www.kde.org/
- Unity - https://unity.ubuntu.com/
- Cinnamon - http://cinnamon.linuxmint.com/
- XFCE - http://www.xfce.org/
- Android Desktop / ChromeOS
The most common Linux distribution releases:
- server - no X11 and no desktop
- desktop - X11 and desktop

X11 installation⌘

Standard installation:

cd /usr/src
wget http://xorg.freedesktop.org/releases/individual/xserver/xorg-server-1.15.99.903.tar.gz
tar -xzf xorg-server-1.15.99.903.tar.gz
cd xorg-server-1.15.99.903
./configure
make
make install

Package-based installation:
- CentOS:

yum groupinstall "X Window System"

- Debian:

apt-get install x-window-system

Some distributions support installation of both X11 and default desktop in one:
- Ubuntu:

apt-get install ubuntu-desktop

X11 configuration⌘

/etc/X11/xorg.conf - main X11 configuration file:

Section [SectionName]
    [SectionEntry]
    ...
EndSection

man xorg.conf

Section entries:
- InputDevice - keyboard and mouse
- Monitor - monitor
- Device - video card
- Screen - monitor and video card combination
- Display - video mode
- Files - font server
Automatic X11 configuration (X Server must be stopped):

X -configure
mv /root/xorg.conf /etc/X11/xorg.conf

X11 management⌘

Management tools:
- startx - starts the X Server
- xdpyinfo - displays information about the X Server
- xwininfo - displays information about windows
- xhost - access control program for the X Server
DISPLAY environmental variable:
- [hostname]:[display].[screen]
- example: localhost:0.1
Lab Exercise 106.1

106.2 Setup a display manager⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Display manager⌘

Program that allows starting of a session on an X server
The most popular Linux display managers:
- GDM (Gnome Display Manager) - https://wiki.gnome.org/Projects/GDM
- KDM (KDE Display Manager) - https://wiki.archlinux.org/index.php/KDM
- XDM - http://www.pl.freebsd.org/doc/handbook/x-xdm.html
- LightDM - https://wiki.archlinux.org/index.php/LightDM

Logging into the system⌘

Logging into the system without display manager:
- CLI logon
- startx
Logging into the system with display manager:
- GUI logon
Runlevels with graphical modes:
- 2 on Debian
- 5 on RedHat
Changing runlevels:
- telinit - temporarily
- /etc/inittab - permanently

Configuration⌘

GDM:
- /etc/X11/gdm/gdm.conf - main configuration file
- key=value pairs grouped by sections
KDM:
- /etc/X11/kdm/kdmrc - main configuration directory
- key=value pairs grouped by sections
XDM:
- /etc/X11/xdm/xdm-config - main configuration file
- key: value pairs grouped by sections
LightDM:
- /etc/lightdm/lightdm.conf - main configuration file
- key=value pairs grouped by sections

Remote access⌘

With X11:
- Direct Connection
- XDMCP (X Display Manager Control Protocol) - http://en.tldp.org/HOWTO/XDMCP-HOWTO/
- X Forwarding using SSH - http://en.tldp.org/HOWTO/XDMCP-HOWTO/ssh.html
Without X11:
- VNC (Virtual Network Computing) - https://www.realvnc.com/
- RDP (Remote Desktop Protocol) - http://msdn.microsoft.com/en-us/library/aa383015(v=vs.85).aspx
Lab Exercise 106.2

106.3 Accessibility⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Keyboard and mouse accessibility settings⌘

Keyboard repeat time - repeat rate and delay of the keyboard
Sticky keys - causes keyboard modifier keys (Ctrl, Alt and Shift) to "stick" when pressed
Slow keys - requires a key to be pressed for longer than a specified period of time
Bounce/debounce keys - treats multiple press of a key as a single press
Mouse tracking and click options - adjusts mouse tracking and click options
Simulated mouse clicks - simulates mouse click / double click
Mouse emulation/mouse navigation - enables mouse emulation by cursor keypad
Mouse gestures - keyboard shortcuts for mouse
Online keyboard - keyboard emulator

Screen accessibility settings⌘

Fonts - adjust fonts used by the system
Contrast - adjust display contrast
Magnifier - enlarges part of the screen

Assistive technologies⌘

Screen Reader - assists blind people in terms of reading:
- Orca - https://wiki.gnome.org/Projects/Orca
Audio Desktop - assists blind people in terms of writing:
- Emacspeak - http://emacspeak.sourceforge.net/
Baille Display - display for blind people
- BRLTTY - http://mielke.cc/brltty/
Lab Exercise 106.3

First Day - Session IV⌘

Topic 107: Administrative Tasks

http://itekblog.com/wp-content/uploads/2013/03/crontab.png

107.1 Manage user and group accounts and
related system files⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

User and group accounts management⌘

Configuration files:
- /etc/passwd - user database
- /etc/shadow - user password database
- /etc/group - group database
- /etc/gshadow - group password database
Management tools:
- groupadd - creates a group
- groupdel - deletes a group
- groupmod - modifies a group
- passwd - modifies user password
- useradd - creates a user
- userdel - deletes a user
- usermod - modifies a user

/etc/passwd file⌘

Structure:

[username]:[password information]:[UID]:[GID]:[GECOS]:[home directory]:[program]

username - user name / login
password information:
- empty - no password
- x - password hash in /etc/shadow file
- * - account locked
- ! - account locked
UID (User IDentifier) - user number
GID (Group IDentifier) - user group number
GECOS (General Electric Comprehensive Operating System) - user full name and contact information
home directory - a path to user home directory
program - a program which is started when the user logs into the system (e.g. shell)

/etc/shadow file⌘

Structure:

[username]:[hash]:[change date]:[min age]:[max age]:[warn period]:[grace period]:[exp date]:[reserved]

username - user name / login
hash - user password hash
change date - last password change date:
- counted in days starting from the 1st of January 1970
- 0 - user will be asked to change its password during the next login
- empty - date checking disabled
min age - minimum number of days after which the password can be changed
max age - maximum number of days after which the password can be changed
warn period - how many days before password expiration date is the user warned
grace period - how many days after password expiration date can the user log in
exp date - account expiration date counted in days starting from the 1st of January 1970
reserved - reserved for future use

/etc/group file⌘

Structure:

[group name]:[password information]:[GID]:[members]

group name - group name
password information:
- empty - no password
- x - password hash in /etc/gshadow file
- * - account locked
- ! - account locked
GID - group number
members - comma-separated list of users
Lab Exercise 107.1

107.2 Automate system administration tasks
by scheduling jobs⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Scheduling jobs in Linux⌘

Jobs run on regular basis:
- on computers running continuously:
  - cron daemon
- on computers not running continuously:
  - anacron utility
Jobs run once:
- at command

Scheduling jobs to be run on regular basis
on computers running continuously⌘

Configuration files:
- /etc/cron.allow - contains new-line separated list of users allowed to access cron service
- /etc/cron.deny - contains new-line separated list of users denied to access cron service
- /var/spool/cron/* - physical location of crontab files
Management tools:
- crontab - crontab management utility
- crond - cron daemon binary

Crontab⌘

Structure:

[minute] [hour] [DoM] [month] [DoW] [username] [command]

minute - job is executed specified number of minutes after a full hour
hour - job is executed at specified hour
DoM - job is executed on specified day of the month
month - job is executed in specified month
DoW - job is executed on specified day of the week
command - command to be executed by cron
Crontab tricks:
- 1-n - 1, 2, ... , n
- */m - 0, m, 2m, ...
- 0-n/m - 0, m, 2m, ... , n
- x,y,z - x, y, z

Scheduling jobs to be run on regular basis
on computers not running continuously⌘

Anacron utility execution:
- /etc/crontab - on Debian-based systems
- /etc/anacrontab - on RedHat-based systems
Anacron jobs definitions:
- /etc/cron.hourly/* - jobs run on an hourly basis
- /etc/cron.daily/* - jobs run on a daily basis
- /etc/cron.weekly/* - jobs run on a weekly basis
- /etc/cron.monthly/* - jobs run on a monthly basis

Anacrontab⌘

Structure:

[period / period name] [delay] [job-identifier] [command]

period - job is executed each period of days
period name - job is executed daily, weekly, monthly, yearly or annualy
delay - job is executed delay minutes after a full hour
job-identifier - used to identify jobs in anacron messages
command - command to be executed by anacron

Scheduling jobs to be run once⌘

Configuration files:
- /etc/at.allow - contains new-line separated list of users allowed to run the at and batch commands
- /etc/at.deny - contains new-line separated list of users denied to run the at and batch command
Management tools:
- at - queues job for later execution
- atq - lists users's pending jobs
- atrm - deletes user's pending job
Lab Exercise 107.2

107.3 Localisation and internationalisation⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Encoding⌘

Unicode:
- standard for consistent representation of text expressed in most of the world's writing systems
- character set - a list of characters with unique numbers
Character encoding standards:
- ASCII - 7-bit encoding
- ISO-8859 - single-byte encoding
- UTF-8 - multi-byte encoding
Encoding conversion - iconv

Locale⌘

Locale - set of parameters that define user's language, country and other preferences
Structure:

[language]_[territory].[codeset]@[modifier]

- language - language code
- territory - territory code
- codeset - encoding system
- modifier - optional parameters
Management tools:
- locale - displays current locale
- locale-gen - generates locale
Lab Exercise 107.3

Second Day - Session I⌘

Topic 108: Essential System Services

http://wecai.org/wordpress/wp-content/uploads/2012/09/email1.jpg

108.1 Maintain system time⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Basic concepts⌘

Hardware Clock - maintains the time while the computer is turned off
Software Clock - maintains the time while the computer is turned on
GMT (Greenwich Mean Time) - local time in Greenwich adjusted for DST (Daylight Saving Time)
UTC (Coordinated Universal Time) - local time in Greenwich not adjusted for DST
Local Time - GMT adjusted for the time zone
NTP (Network Time Protocol) - a protocol used for time adjustment over the network

Time, date and timezone configuration⌘

Time and date manual configuration:
- hwclock - displays / configures hardware clock
- date - displays / configures software clock
Timezone configuration:
- /usr/share/zoneinfo/* - contains timezones configuration files
- /etc/localtime:
  - specifies timezone used by the system
  - links into a file from /usr/share/zoneinfo directory
- /etc/timezone - specifies timezone name
- dpkg-recofigure tzdata - reconfigures timezone on Debian systems
- tzselect - reconfigures timezone on RedHat systems

NTP configuration⌘

- /etc/ntp.conf - main NTP configuration file:
Client-side configuration and administration tools:
- pointing a client to the server via ntp.conf:

server [server]

- manual update of software time from the server:

ntpdate [server]

Server-side configuration:
- ntpd - NTP server daemon
- ntpq - verifies NTP server operations
pool.ntp.org - virtual cluster of publicly available and reliable time servers
Lab Exercise 108.1

108.2 System logging⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Syslog configuration⌘

/etc/syslog.conf - main syslog configuration file:
- structure:

[facility].[priority] [action]

- facility:
  - specifies a code word for the type of program or tool that generated the message to be logged
  - valid codes: auth, authpriv, cron, daemon, kern, lpr, mail, mark, news, security, syslog, user, uucp, local[0-7], *
- priority:
  - specifies a code word for the priority the message below which it is not logged
  - valid codes: *, debug, info, notice, warning, warn, error, err, crit, alert, emerg, panic
- action:
  - specifies a file into which the messages is logged
  - a file can be a log file, device, remote syslog server ('@server') or all logged users ('*')
/etc/rsyslog.conf - main rsyslog configuration file

Syslog central log server⌘

Client:
- point syslog daemon to send messages to the remote syslog server

[facility].[priority] @[server]

Server:
- install syslog-ng package
- edit /etc/syslog-ng/syslog-ng.conf and include the following entries to accept all messages over the network:

source s_all {
    udp();
};
...
log { source(s_all); filter(f_syslog3); destination(d_syslog); };

- perform additional configuration (man syslog-ng.conf)

Other logging tools⌘

logger:
- used to create log entry manually
- example:

logger Sample Message

klogd:
- reads and logs Linux kernel messages
- example:

klogd -o -f /var/log/kernel

logrotate:
- used to automatically rotate logs

Lab Exercise 108.2

108.3 Mail Transfer Agent (MTA) basics⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Email foundations⌘

Email architecture:
- MUA (Mail User Agent) - formats user message in email format and submits it into the MSA
- MSA (Mail Submission Agent) - determines MTA into which an email should be send
- MTA (Mail Transfer Agent) - delivers an email into another MTA
- MDA (Mail Delivery Agent) - delivers an email into user mailbox
Email protocols:
- SMTP (25) - used to send email between MTAs
- Submission (587) - used to send email from MUA to MSA
- POP3 (110) - used to get email from mailbox
- IMAP (143) - used to manage mailbox
Email DNS records:
- MX - edge MTAs in the domain
- SPF - prevents email spoofing

MTA⌘

The most popular Linux MTAs:
- Postfix - http://www.postfix.org/
- Exim - http://www.exim.org/
- Sendmail - http://www.sendmail.com/sm/open_source/
- Qmail - http://www.qmail.org/
The most popular Linux colaboration suites with MTA:
- Zimbra - http://www.zimbra.com/
- Scalix - http://www.scalix.com/

Aliases⌘

Define email address of system users
/etc/aliases.db - aliases database
/etc/aliases - aliases configuration file
- format:

[alias]: [email address | alias], [email address | alias], ...

- example:

postmaster:   root
root:         IT@mycompany.com, MyCompanyIT@gmail.com

newaliases - updates aliases database

MTA management⌘

Management tools:
- mailq - displays mail queue
- mail - displays mailbox content
- ~/.forward - email forwarding configuration file:
  - list of forwarders
  - avoid infinite loops by using the '\' prefix
Lab Exercise 108.3

108.4 Manage printers and printing⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Print queue⌘

Holding area where files wait to be printed
/var/spool/cups/* - physical location of the print queue
A single compute can support many distinct print queues
Jobs are submitted to the print queue by the lpr program
Can be managed in terms of jobs monitoring, ordering, deleting, etc.
Network oriented - jobs can be submitted over the network

PostScript and Ghostscript⌘

PostScript:
- printer language
- de facto standard for Linux
Ghostscript:
- PostScript interpreter
- used for printers incompatible with PostScript

CUPS configuration⌘

/etc/cups - main configuration directory:
- cupsd.conf - CUPS daemon configuration file
- printers.conf - printer definitions
- classes.conf - printer classes
- client.conf - CUPS client configuration
- lpoptions - printer options
- subscriptions.conf - active subscriptions
- ppd/* - additional options (PostScript Printer Definition)
The easiest way to add a printer is to do it from the GUI
CUPS web interface: http://localhost:631

CUPS management⌘

Management tools:
- lpr - prints a file
- lpq - displays print queue status
- lpc - displays printers status
- lprm - removes a job from the print queue
Lab Exercise 1.8.4

Second Day - Session II⌘

Topic 109: Networking Fundamentals

http://villagecom.com/wp-content/uploads/2012/03/network_cabling1.jpg

109.1 Fundamentals of internet protocols⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

TCP/IP protocol stack⌘

http://www.phaedsys.com/principals/segger/seggerimages/embosip_struct1.gif

MAC address⌘

The most common link layer networks:
- Ethernet (802.1)
- WiFi (802.11)
MAC (Media Access Control) address:
- used to uniquely identify a host in link layer
- 48 bits
- 12 hex values
- consists of:
  - OUI (Organisationally Unique Identifier) - 24 bits
  - NIC (Network Interface Controller) - 24 bits
- physically bound to the interface, but can be changed programmatically
- can coexist in 2 networks separated by a router

IP address⌘

IP (Internet Protocol) address:
- used to uniquely identify a host in network layer
- 32 bits
- 4 decimal octests separated by dots
- consists of:
  - Network Part delimited by a Subnet Mask
  - Host Part delimited by a Subnet Mask
- special purpose addresses:
  - network address
  - broadcast address
- programmatically bound to the interface
- can not coexist in 2 networks separated by a router

Default gateway⌘

IPv4 vs IPv6⌘

Feature	IPv4	IPv6
IP address	32 bits	128 bits
Checksum	Header includes checksum	Header does not include checksum
Options	Header includes options	Extension headers
Broadcast IP address	Available	Not available; link-local IP address
IP address configuration	Manual or DHCP-based	Auto-configuration

ICMP, TCP and UDP protocols⌘

ICMP (Internet Control Message Protocol):
- used to send error messages between network hosts
- used to test network connectivity (ping)
TCP (Transmission Control Protocol):
- the most widely used transport-layer protocol in the TCP/IP stack
- creates full connection for with error checking, acknowledgements, etc.
- used to ensure reliable data transmission
UDP (User Datagram Protocol):
- best-effort transport-layer protocol
- does not create a connection between network hosts
- used in cases when reliable data transmission is not important or is provided by upper layer protocols

Network services⌘

Port	Protocol	Service	Example Linux Implementation
20	TCP	FTP data	ProFTPd
21	TCP	FTP	ProFTPd
22	TCP	SSH	OpenSSH
23	TCP	Telnet	in.telnetd
25	TCP	SMTP	Postfix
53	TCP / UDP	DNS	BIND
80	TCP	HTTP	Apache
110	TCP	POP3	Dovecot

Network services #2⌘

Port	Protocol	Service	Example Linux Implementation
119	TCP	NTTP	InterNetNews
139	TCP	Windows file sharing	Samba
143	TCP	IMAP	Dovecot
161	UDP	SNMP	Net-SNMP
443	TCP	HTTPS	Apache
465	TCP	SMTPS	Postfix
993	TCP	IMAPS	Dovecot
995	TCP	POP3S	Dovecot

Basic IP configuration⌘

Configuration files:
- /etc/protocols - IP protocols and their numbers

[protocol number] [protocol name] [protocol aliases] #[comment]

- /etc/services - TCP / UDP services and their ports

[service name] [port]/[protocol] [service aliases] #[comment]

Lab Exercise 109.1

109.2 Basic network configuration⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Network interfaces configuration⌘

Configuration files:
- /etc/network/interfaces - on Debian systems
- /etc/sysconfig/network-scripts/ifcfg-[interface name] - on RedHat systems
Configuration tools:
- ifconfig - network interface configuration tool
- ifup - brings network interface up
- ifdown - brings network interfac down

Network interfaces configuration - Debian⌘

auto [interface name]
iface [interface name] inet [dhcp | static]
address [IP]
netmask [SM]
network [network IP]
broadcast [broadcast IP]
gateway [DG]

Network interfaces configuration - RedHat⌘

DEVICE=[interface name]
ONBOOT=[no | yes]
BOOTPROTO=[dhcp | none]
IPADDR=[IP]
NETMASK=[SM]
NETWORK=[network IP]
BROADCAST=[broadcast IP]
GATEWAY=[DG]

Routing configuration⌘

Manual:
- route command:

route add -net [network IP] netmask [SM] gw [next hop IP] [interface name]

- ip route command:

ip route add [network IP / SM] via [next hop IP] dev [interface name]

Via configuration files:
- Debian (/etc/network/interfaces):

up [manual command]

- RedHat (/etc/sysconfig/network-scripts/route-[interface name]):

[network IP/ SM] via [next hop IP] dev [interface name]

Lab Exercise 109.2

109.3 Basic network troubleshooting⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Network troubleshooting tools⌘

host - simple DNS lookup tool
dig - advance DNS lookup tool
hostname - system hostname management tool
ping - sends ICMP ECHO_REQUEST packet to network host
traceroute - prints the route packets trace to network host
tracepath - prints the route and MTU packets trace to network host
telnet - establishes TCP session with any server
ftp - establishes TCP session with FTP server
Lab Exercise 109.3

109.4 Configure client side DNS⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

NSS, resolver, DNS and hostname configuration⌘

Resolver and DNS configuration files:
- /etc/nsswitch.conf - NSS (Name Service Switch) configuration file:

hosts: files dns

- /etc/hosts - resolver configuration file:

[IP] [domain name]

- /etc/resolv.conf - DNS (Domain Name System) configuration file:

search [domain 1] [domain 2] ...
nameserver [IP 1]
nameserver [IP 2]
...

- Hostname configuration file:
  - /etc/hostname - on Debian-based systems
  - /etc/sysconfig/network - on RedHat-based systems
Lab Exercise 109.4

Second Day - Session III⌘

Topic 110: Security

http://blogs.salleurl.edu/nice-rack/files/2014/05/infosec.jpg

110.1 Perform security administration tasks⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Security audit⌘

Security audit definition (via searchcio.techtarget.com):

"A security audit is a systematic evaluation of the security of a company's information system by measuring how well it conforms to a set of established criteria."

Security audit types:
- system scans
- network scans
- processes reviews
- policies reviews
- attacks

SUID and SGID bits⌘

SUID (Set User ID):
- causes that users executing the program will inherit owner's permissions, UID and GID
- setup as an s character on third bit in standard access rights
- dangerous if an owner of the program is root
SGID (Set Group ID):
- causes that newly created files and subdirectories in the directory will inherit GID
- setup as an s character on sixth bit in standard access rights
- dangerous if a group of the directory is root
Finding files and directories with SUID and SGID bits setup:

find / -perm -u+s
find / -perm -g+s

Listing open files:

lsof

Password management⌘

Changing user password:

passwd [username]

Password and account expiration management:
- chage - used for password expiration management
- usermod - used for account expiration management
- examples:
  - 1 year password expiration period:

chage -M 365 user

- - 1 month account expiration period:

usermod -f 30 user

Network scans⌘

nmap - scans open ports on a system by sending a bunch of TCP / UDP packets over the network:
- useful options:
  - -p - specifies port, ports or a port range to scan
  - -sU - specifies that UDP scan should be performed
- example:

nmap -p 80,443 google.com

netstat - scans open ports on a local system by displaying a list of open sockets:
- useful options:
  - -t - limits the output to show TCP connections only
  - -a - shows both listening and non-listening sockets
  - -p - shows PID of the process to which the socket belongs to
  - -n - does not attempt to reverse resolve domain names
- example:

netstat -atpn | grep 631 | head -n 1 | awk '{print $7}'

Security limits⌘

/etc/security/limits.conf - main security limits configuration file:
- structure:

[domain] [type] [item] [value]

- domain - username or group ('@')
- type - 'soft' or 'hard'
- item - system resource
- value - limit value
ulimit - security limits management tool:

ulimit -a

Sudo configuration⌘

Management tools:
- sudo - executes single command as another user
- su - switches into another user space
- gksudo / gksu - graphical versions of sudo / su
- visudo - used to edit /etc/sudoers file
/etc/sudoers - sudo configuration file:
- example:

admin ALL=(ALL:ALL)NOPASSWD ALL

- explanation:
  - admin - the rule applies to admin user
  - first ALL - the user can run commands from any host
  - second ALL - the user can run commands as any user
  - third ALL - the user can run commands as any group
  - NOPASSWD - the user does not need to type a password to run commands
  - fourth ALL - the rule applies to any commands
Lab Exercise 110.1

110.2 Setup host security⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

Super server⌘

Listens for network connections on behalf of another program
When a connection is initiated, hands off control of that connection to the intended server
Reduces memory load if the super server handles many small servers that are seldom used
Enhanced security thanks to the tcp wrappers
Linux super servers:
- inetd - standard super server
- xinetd - enhanced super server

Inetd configuration⌘

/etc/inetd.conf - main inetd configuration file:
- structure:

[service name] [socket type] [protocol] [wait / nowait] [user] [server name] [parameters]

- service name - name of the service from /etc/services file
- socket type - type of connection: stream, dgram, raw, seqpacket
- protocol - name of the protocol from /etc/protocols file
- wait / nowait - specifies whether all packets are processed before closing the socket
- user - username used to run the server
- server name - server executable path
- parameters - server parameters
service inetd restart - restarts inetd super server

TCP wrapper⌘

TCP wrapper - allows access to particular services from specified IP addresses only
/usr/sbin/tcpd - TCP wrapper executable
/etc/hosts.allow, /etc/hosts.deny - TCP wrapper configuration files:
- structure:

[daemon list]: [client list]

- daemon list - list of services from the /etc/services file
- client list - list of clients
Running services via TCP wrapper:

[service name] [socket type] [protocol] [wait / nowait] [user] /usr/sbin/tcpd [server name] [parameters]

Xinetd configuration⌘

/etc/xinetd.conf - main xinetd configuration file:
- structure:

service [service name]
{
    socket_type   = [socket type]
    protocol      = [protocol]
    wait          = no / yes
    user          = [user]
    server        = [server name]
    server_args   = [parameters]
    only_from     = [hosts.allow file path]
    no_access     = [hosts.deny file path]
}

service xinetd restart - restarts xinetd super server

Additional security concerns⌘

Listing unused network services:

netstat -tap

Temporarily disabling login for non-root users:
- /etc/nologin
- file content is displayed and the loggin attempt fails
Lab Exercise 110.2

110.3 Securing data with encryption⌘

https://www.lpi.org/linux-certifications/programs/lpic-1/exam-102/

SSH⌘

SSH (Secure SHell) - cryptographic network protocl to secure data communication
SSH packages:
- openssh-server - SSH server
- openssh-client - SSH client
SSH derivatives:
- SCP (Secure CoPy) - used to copy files over the network via SSH
- SSH Tunneling - used to wrap any kind of connection in an SSH

SSH architecture⌘

http://docstore.mik.ua/orelly/networking_2ndEd/ssh/figs/ssh_0304.gif

SSH configuration⌘

/etc/ssh/ssh_config - main client configuration file
/etc/ssh/sshd_config - main server configuration file
/etc/ssh/ssh_host_rsa_key - host private RSA key
/etc/ssh/ssh_host_rsa_key.pub - host public RSA key
/etc/ssh/ssh_host_dsa_key - host private DSA key
/etc/ssh/ssh_host_dsa_key.pub - host public DSA key
~/.ssh/id_rsa - user private RSA key
~/.ssh/id_rsa.pub - user public RSA key
~/.ssh/id_dsa - user private DSA key
~/.ssh/id_dsa.pub - user public DSA key
~/.ssh/known_hosts - server fingerprints accepted by a user
~/.ssh/authorized_keys - public keys of users allowed to SSH into the user account

SSH management⌘

Management tools:
- ssh - runs SSH client
- ssh-keygen - used to create and manage private-public key pairs
- ssh-agent - program used to hold and remember the passphrace for private key
- ssh-add - adds user public key into the ~/.ssh/authorized_keys file
SSH agent forwarding:
- /etc/ssh/ssh_config:

ForwardAgent yes

- /etc/ssh/sshd_config:

AllowAgentForwarding yes

SSH tunneling⌘

/etc/ssh/sshd_config:

AllowTcpForwarding yes

tunnel establishment:

ssh -N -f -L [local port]:[remote host]:[remote port] [username]@[remote host]

GPG⌘

GPG (GNU Privacy Guard) - email encryption tool
~/.gnupg - user configuration directory
GPG private-public key pair generation:

gpg --gen-key

GPG public key export:

gpg --export [name] > [file]

GPG public key import:

gpg --import [file]

Listing GPG keys:

gpg --list

GPG usage⌘

Encrypting data with GPG:

gpg --out [encrypted file] --recipient [UID] --armor --encrypt [decrypted file]

Decrypting data with GPG:

gpg --out [decrypted file] --decrypt [encrypted file]

Signing messages with GPG:

gpg --clearsign [file]

Verifying signatures with GPG:

gpg --verify [file]

Lab Exercise 110.3

Second Day - Session IV⌘

Case Study, Certification and Surveys

http://zone16.pcansw.org.au/site/ponyclub/image/fullsize/60786.jpg

Certification and Surveys⌘

Congratulations on completing the course!
Official Certification:
- LPI: https://www.lpi.org
- Paerson VUE: http://www.pearsonvue.com/
- Prometric: https://www.prometric.com/en-us/Pages/home.aspx
Visit http://www.nobleprog.com for other courses
Surveys: http://www.nobleprog.pl/te

Questions⌘

Thank you very much for your attention

LPIC-102

Copyright Notice

What does Linux mean?⌘

Outline⌘

Outline #2⌘

First Day - Session I⌘

LPI certification path⌘

LPIC-101 exam⌘

Introduction to the lab⌘

First Day - Session II⌘

105.1 Customize and use the shellenvironment⌘

Environmental Variables⌘

Bash configuration files⌘

Other bash customization tools⌘

105.2 Customize or write simple scripts⌘

Bash scripting foudations⌘

IO Operations⌘

Conditional expressions⌘

Loops⌘

105.3 SQL data management⌘

SQL and RDBMS⌘

Basic SQL commands⌘

First Day - Session III⌘

106.1 Install and configure X11⌘

What is X11?⌘

History of X11⌘

History of X11 #2⌘

Desktops⌘

X11 installation⌘

X11 configuration⌘

X11 management⌘

106.2 Setup a display manager⌘

Display manager⌘

Logging into the system⌘

Configuration⌘

Remote access⌘

106.3 Accessibility⌘

Keyboard and mouse accessibility settings⌘

Screen accessibility settings⌘

Assistive technologies⌘

First Day - Session IV⌘

107.1 Manage user and group accounts andrelated system files⌘

User and group accounts management⌘

/etc/passwd file⌘

/etc/shadow file⌘

/etc/group file⌘

107.2 Automate system administration tasksby scheduling jobs⌘

Scheduling jobs in Linux⌘

Scheduling jobs to be run on regular basison computers running continuously⌘

Crontab⌘

Scheduling jobs to be run on regular basison computers not running continuously⌘

Anacrontab⌘

Scheduling jobs to be run once⌘

107.3 Localisation and internationalisation⌘

Encoding⌘

Locale⌘

Second Day - Session I⌘

108.1 Maintain system time⌘

Basic concepts⌘

Time, date and timezone configuration⌘

NTP configuration⌘

108.2 System logging⌘

Syslog configuration⌘

Syslog central log server⌘

Other logging tools⌘

108.3 Mail Transfer Agent (MTA) basics⌘

Email foundations⌘

MTA⌘

Aliases⌘

MTA management⌘

108.4 Manage printers and printing⌘

Print queue⌘

PostScript and Ghostscript⌘

CUPS configuration⌘

CUPS management⌘

Second Day - Session II⌘

109.1 Fundamentals of internet protocols⌘

TCP/IP protocol stack⌘

MAC address⌘

IP address⌘

105.1 Customize and use the shell
environment⌘

107.1 Manage user and group accounts and
related system files⌘

107.2 Automate system administration tasks
by scheduling jobs⌘

Scheduling jobs to be run on regular basis
on computers running continuously⌘

Scheduling jobs to be run on regular basis
on computers not running continuously⌘
